2000kg ATM Load Rating
- Checker Plate FLOOR
- Main Chassis RAILS Full Length 100x50x3mm RHS
- Heavy duty chassis 50×50 SHS
- DRAW BAR 100X50x3mm RHS
- Full length side tie rails under the chassis
- SPARE WHEEL HOLDER mounted on the draw bar
- Swing up H/Duty 750KG 10X3″ Jockey Wheel
- MECHANICAL DISC BRAKES
- 50MM OVERRIDE LOCKABLE COUPLING
ADVANCED – INDEPENDENT TORSION SUSPENSION (ITS)
- LED 12-24v lights with 7-pin large round plug
- Front LED clearance Lights
- Front & sides reflectors
- Large mud flaps 300x230mm
- Brand new 14” Sunraysia Rims with 185C new tyres
- BODY SCRAPED TO REMOVE AS MUCH WELDING SPLATTER AS POSSIBLE – CLEANED WITH WAX & GREASE REMOVER
- CHASSIS & TOP ETCH PRIMED THEN FINISHED WITH TOP OF TRAILER COATED IN HIGH QUALITY POLYTHANE 2-PACK PAINT
WHAT IS ITS SUSPENSION: INDEPENDENT TORSION SUSPENSION
ITS axles have a straightforward, attached construction with a torsion suspension system. Four rubberized cords are inside the axle housing which handle suspension travel and shock absorption. In addition, this system offers trailer rigidity as the axle is bolted to the trailer frame.
The main advantages of a torsion bar suspension are soft ride due to elasticity of the bar, durability, and small profile along the width of the vehicle.
Smother ride & lower more ground clearance:
Self-damping action and independent suspension, ITS delivers a smooth, quiet ride like no other – adding up to an improved towing experience. Also, by bolting the axle up close to the chassis this give more ground clearance than traditional spring & axle setup.
Except for periodic inspection of the fasteners used to attach the ITS axle to the Trailer frame, no other suspension maintenance is required on ITS axles. They are, of course, subject to normal maintenance and inspection procedures regarding brakes, hubs, bearings, seals, wheels and tyres.
Traditional leaf springs, axles and all the componentry may fatigue over time and break whereas the ITS suspension has less componentry eliminating this issue.
