2000kg ATM Load Rating
- FULL CHECKER PLATE FLOOR
- RHS CHASSIS
- DRAW BAR 100X50X4 RHS WITH SUPPORT TUBE WELDED UNDERNEATH
- TIE POINTS
- 300×1800 LONG CHECKER PLATE RAMPS
- RAMPS SLIDE UNDER CHASSIS IN A RAMP CRADLE
- WHEEL STOPPERS
- DOUBLE FOLDED CHECKER PLATE GUARDS FOR A MODERN LOOK
- SPARE WHEEL HOLDER
- 50MM COUPLING
ADVANCED – INDEPENDENT TORSION SUSPENSION (ITS)
- MECHANICAL DISC BRAKES
- CABBLE HAND BRAKE
- FRONT & SIDES REFLECTORS
- LED 12V LIGHTS (All Joins soldered)
- RUBBER MUDFLAPS
- BRAND NEW RIMS WITH NEW TYRES
- BODY SCRAPED TO REMOVE AS MUCH WELDING SPLATTER AS POSSIBLE – CLEANED WITH WAX & GREASE REMOVER, THE CHASSIS & TOP ETCH PRIMED THEN FINISHED WITH TOP OF TRAILER COATED IN HIGH QUALITY POLYTHANE 2-PACK PAINT
WHAT IS ITS SUSPENSION: INDEPENDENT TORSION SUSPENSION
ITS axles have a straightforward, attached construction with a torsion suspension system. Four rubberized cords are inside the axle housing which handle suspension travel and shock absorption. In addition, this system offers trailer rigidity as the axle is bolted to the trailer frame.
The main advantages of a torsion bar suspension are soft ride due to elasticity of the bar, durability, and small profile along the width of the vehicle.
Smother ride & lower more ground clearance:
Self-damping action and independent suspension, ITS delivers a smooth, quiet ride like no other – adding up to an improved towing experience. Also, by bolting the axle up close to the chassis this give more ground clearance than traditional spring & axle setup.
Except for periodic inspection of the fasteners used to attach the ITS axle to the Trailer frame, no other suspension maintenance is required on ITS axles. They are, of course, subject to normal maintenance and inspection procedures regarding brakes, hubs, bearings, seals, wheels and tyres.
Traditional leaf springs, axles and all the componentry may fatigue over time and break whereas the ITS suspension has less componentry eliminating this issue.
Pictures displayed are for illustrative purpose only & may show more or less features that are fitted standard
