2000kg ATM Load Rating
- CHECKER PLATE FLOOR
- HEAVY DUTY CHASSIS
- DRAW BAR 100X50X4 RHS WITH SUPPORT TUBE WELDED UNDERNEATH
- RUBBER MUDFLAPS
- SIDE TIE RAILS (FULL LENGTH UNDER CHASSIS)
- CABLE HAND BRAKE
- 50MM COUPLING
- FRONT & SIDES REFLECTORS
- BRAND NEW 14” SUNRAYSIA RIMS WITH 185C NEW TYRES
ADVANCED – INDEPENDENT TORSION SUSPENSION (ITS)
- MULTI STAGE HYDRAULIC RAM
- SINGLE ACTING ELECTRIC PUMP
- LOCKABLE TOOLBOX RECESSED IN THE DRAW BAR THAT HOUSES THE PUMP, BATTERY & SWITCH
- LED 12V LIGHTS WITH 7-PIN FLAT PLUG (ALL JOINS SOLDERED)
- BODY SCRAPED CLEANED & WASHED, EXTERIOR JOINTS SEALED WITH STICKAFLEX TO PREVENT MOISTER
- THE COMPLETE TRAILER INCLUDING THE CHASSIS ETCH PRIMED & THEN FINISHED WITH A TOP COAT OF HIGH QUALITY POLYTHANE 2-PACK PAINT
WHAT IS ITS SUSPENSION: INDEPENDENT TORSION SUSPENSION
ITS axles have a straightforward, attached construction with a torsion suspension system. Four rubberized cords are inside the axle housing which handle suspension travel and shock absorption. In addition, this system offers trailer rigidity as the axle is bolted to the trailer frame.
The main advantages of a torsion bar suspension are soft ride due to elasticity of the bar, durability, and small profile along the width of the vehicle.
Smother ride & lower more ground clearance:
Self-damping action and independent suspension, ITS delivers a smooth, quiet ride like no other – adding up to an improved towing experience. Also, by bolting the axle up close to the chassis this give more ground clearance than traditional spring & axle setup.
Except for periodic inspection of the fasteners used to attach the ITS axle to the Trailer frame, no other suspension maintenance is required on ITS axles. They are, of course, subject to normal maintenance and inspection procedures regarding brakes, hubs, bearings, seals, wheels and tyres.
Traditional leaf springs, axles and all the componentry may fatigue over time and break whereas the ITS suspension has less componentry eliminating this issue.
Pictures displayed are for illustrative purpose only & may show more or less features that are fitted standard
